A compact 1-section, 1-spool monoblock directional valve with pneumatic actuation, designed for stable flow control up to 40 L/min and 1 MPa, operating reliably across wide viscosity and extreme ambient temperatures.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
Control & structure: Pneumatic-operated, single-section monoblock design reduces external leak points and simplifies installation for OEM integration.
Performance: Rated flow 40 L/min (10.5 US gpm) with max pressure 1 MPa (145 psi), suitable for pneumatic-driven directional switching in compact circuits.
Fluid & environment adaptability: Supports 12–400 mm²/s viscosity range and ambient temperatures from -40°C to +80°C, helping maintain consistent operation in cold storage, outdoor equipment, and variable-duty industrial environments.
Typical applications: Directional control for actuators and mechanisms on material handling and industrial vehicles (e.g., forklifts, stackers, aerial platforms), as well as selected construction/agricultural auxiliary functions where pneumatic control is preferred.
Supply capabilities: Factory direct manufacturing for global markets—OEM/ODM, private label, customization (ports, mounting, interfaces, labeling/packaging), wholesale, and distributor/agent cooperation.
| BKQF34 Series Pneumatic Control Valve Parameters | |
|---|---|
| Control Method | Manual |
| Spool | 1 Spool |
| Section | 1 Section |
| Structure Type | Monoblock valve |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 1 MPa (145 psi) |
| Operating Viscosity Range | 12 - 400 mm²/s (12 cSt to 400 cSt) |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
