100 cc/rev external gear pump with cast iron body, ISO-4 flange mounting and rectangle spline shaft, supporting right/left rotation. Rated to 20 MPa (17 MPa option) with 25 MPa max pressure at up to 2500 r/min for demanding mobile and industrial hydraulic systems.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This external gear pump is designed for stable flow output in open-circuit hydraulic systems used on mobile equipment and industrial vehicles. Key specs: 100 cc/rev displacement; rated pressure 20 MPa (or 17 MPa) and max pressure 25 MPa; rated/max speed 2500 r/min; rotation options clockwise (R) or counter-clockwise (L). Build and interfaces: durable cast iron housing, ISO-4 mounting holes for easy interchange, and H-type rectangle spline shaft for reliable torque transmission. Typical applications include forklifts/telehandlers (lift and steering circuits), skid steer loaders and loaders (auxiliary hydraulics), excavators/backhoes (implement circuits), tractors and agricultural machines (hydraulic functions), plus sweepers and waste compactors. Available for OEM/ODM manufacturing, private label, customization, wholesale supply, and distributor/agent cooperation for global markets.
| C102 Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 90 cc/rev, 112 cc/rev |
| Rated Pressure | 17 MPa (2465 psi), 20 MPa (2900 psi) |
| Max Pressure | 25 MPa (3625 psi) |
| Rated Speed | 2500 r/min |
| Max Speed | 2500 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise) |
| Structure | External Gear Pump |
| Material | Cast Iron |
| Flange Version | ISO-4 Mounting Holes |
| Shaft Type | H: Rectangle Spline |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
