A 100 cc/rev internal hydraulic gear pump with cast-iron housing, rated 16 MPa and up to 20 MPa, designed for reliable flow delivery in mobile and industrial hydraulic systems with multiple rotation and shaft/flange options.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
The JHP2100 series 100 cc/rev internal gear pump is built for demanding mobile hydraulics where stable output, durability, and easy integration are required. Rated pressure is 16 MPa (2320 psi) with a maximum of 20 MPa (2900 psi), supporting high-load work functions such as lifting, steering, auxiliary circuits, and implement hydraulics.
Key specifications:
- Displacement: 100 cc/rev for higher flow per revolution
- Speed: 2000 r/min rated, 2200 r/min max
- Rotation: right-hand (clockwise) or left-hand (counter-clockwise)
- Structure: internal gear design for smooth, consistent delivery and low pulsation
- Material: cast iron body for strength, wear resistance, and long service life
- Mounting: B-square flange for common equipment interfaces
- Shaft options: rectangle spline (H) or plain key (P) for flexible drivetrain matching
Typical applications include material handling and construction equipment (forklifts, telehandlers, skid steer loaders, wheel loaders, mini-excavators), as well as agricultural machines and various industrial vehicles.
Supply capabilities: manufacturer direct support for OEM/ODM, private label, customization, and wholesale; we also welcome global distributors, agents, and traders.
| JHP Tandem Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 10 cc/rev, 40 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 16 cc/rev |
| Rated Speed | 2000 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise) |
| Rated Pressure | 16 MPa (2320 psi) |
| Shaft Type | H: Rectangle Spline, P: Plain Key |
| Max Pressure | 20 MPa (2900 psi) |
| Structure | Internal Gear Pump |
| Max Speed | 2200 r/min |
| Flange Version | B-Square Flange |
| Material | Cast Iron |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
