110 cc/rev high-displacement gear pump with bidirectional rotation, up to 25 MPa max pressure and 2500 r/min max speed. Cast-iron design with UNI-3 A-oval flange and multiple shaft options for mobile and industrial hydraulic systems.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
Key specs: 110 cc/rev displacement; rated pressure 20 MPa (2900 psi) / 25 MPa (3625 psi); max pressure 25 MPa (3625 psi); rated speed 2000 r/min; max speed 2500 r/min; bidirectional rotation. Construction: gear pump architecture (internal/external configurations), cast iron body for strength, durability, and vibration resistance in heavy-duty service. Installation options: UNI-3 mounting holes with A-oval flange for common OEM fitment and easier replacement in existing manifolds/frames. Shaft options: H rectangle spline for high-torque transmission; P plain key for standard coupling compatibility. Typical applications: mobile hydraulics requiring stable flow for lifting, steering, conveyor/boom actuation, and auxiliary circuits—commonly used in material handling equipment, construction machines, agricultural machinery, and industrial vehicles. Supply capabilities: manufacturer direct support for OEM/ODM, private label, customization, wholesale, and distributor/agent partnerships for global markets.
| BF Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 63 cc/rev, 80 cc/rev, 110 cc/rev, 43 cc/rev |
| Rated Pressure | 20 MPa (2900 psi), 25 MPa (3625 psi) |
| Rated Speed | 2000 r/min |
| Structure | External Gear Pump, Internal Gear Pump |
| Material | Cast Iron |
| Shaft Type | H: Rectangle Spline, P: Plain Key |
| Flange Version | A-Oval Flange, UNI-3 Mounting Holes |
| Max Pressure | 25 MPa (3625 psi) |
| Rotation | /: (Bidirectional) |
| Max Speed | 2500 r/min |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
