A heavy-duty, pressure-lubricated gearbox PTO with 1:1 speed ratio and 479.7 Nm rated output torque, using pneumatic single-acting actuation with spring return and opposite output rotation for reliable auxiliary drive.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This PTO is designed to transmit up to 479.7 Nm rated torque at a 1:1 speed ratio for driving auxiliary equipment (e.g., hydraulic pumps) from a compatible drivetrain/gearbox. It features a Standard Mount interface for straightforward installation and Pressure Lube lubrication to improve durability under continuous duty and high load. Engagement is managed by a Pneumatic single-acting cylinder with spring reset, requiring 6 bar control air pressure for stable, fast actuation and fail-safe return. Output rotation is opposite to the engine steering direction, supporting specific pump/attachment rotation requirements. Suitable for industrial vehicles and construction/material-handling machines such as telehandlers, forklifts, cranes, loaders, concrete boom pumps, sweepers, and compactors. Available for OEM/ODM, private label, customization, bulk supply, and distributor/agent cooperation for global markets.
| ZF50 Series Power Take Off Parameters | |
|---|---|
| Control Air Pressure | 6 bar |
| Mounting Type | 4 bolt |
| Output Steering | Opposite to the engine steering direction |
| Manipulation Form | Pneumatic (single acting cylinder) spring reset |
| Speed Ratio | 1:1 |
| Rated Output Torque | 479.7 Nm |
| Lube Option | Pressure Lube |
| Mounting Option | Standard Mount |
