A compact 3-section solenoid-operated monoblock hydraulic control valve designed for mobile machinery, delivering up to 80 L/min flow and 315 bar pressure with reliable operation across wide viscosity and ambient temperature ranges.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This solenoid-actuated, 3-section monoblock valve is built for mobile hydraulic systems requiring high flow control and stable directional switching. Rated flow is 80 L/min with maximum pressure up to 315 bar, supporting demanding cylinder or motor control tasks. The monoblock structure improves rigidity, reduces potential leak paths, and simplifies installation for OEM equipment.
Key operating compatibility includes 15–75 mm²/s hydraulic oil viscosity and an ambient temperature range from -40°C to +80°C, making it suitable for both cold-start outdoor equipment and high-heat jobsite environments. Typical applications include material handling and construction machines (forklifts, telehandlers, aerial platforms, skid steers, loaders, excavators) as well as agricultural equipment where electric/remote control and repeatable actuation are required.
We support manufacturing, OEM/ODM, private labeling, customization, and wholesale supply for global customers, and we are actively seeking distributors, agents, wholesalers, and trading partners.
| P80 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Rated Flow | 80 L/min (21.2 US gpm) |
| Max Pressure | 315 bar (4600 psi) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
