Compact 4-spool electro-hydraulic monoblock directional control valve designed for mobile machinery, delivering 40 L/min flow and up to 250 bar pressure with stable operation across wide viscosity and temperature ranges.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This electro-hydraulic monoblock directional valve features 4 spools in a compact one-piece body for reduced leakage paths, simplified installation, and high reliability in mobile and industrial hydraulic systems. Rated flow is 40 L/min with max pressure up to 250 bar, suitable for multi-actuator control (cylinders/motors) on equipment requiring remote electric actuation. Designed to work with hydraulic oils from 15–75 mm²/s and ambient temperatures from -40°C to +80°C, it supports cold-start and high-heat job sites.
Typical applications include telehandlers, forklifts/stackers, aerial platforms, skid steer loaders, mini-excavators, wheel loaders, backhoe loaders, dumpers, and tractor front-end loaders—where electro-hydraulic control improves operator comfort, enables cab/remote control layouts, and supports integration with switches, joysticks, or machine control systems.
Supply capabilities: manufacturing, OEM/ODM, private label, customization and wholesale. Custom options commonly include port thread types, mounting interface, electrical voltage/connectors, spool function configuration, and pressure setting requirements to match your machine circuit.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic and Manual, Cable, Joystick, Solenoid and Joystick |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Max Pressure | 250 bar (3600 psi) |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Structure Type | Monoblock valve |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
