4-spool monoblock directional control valve with hydraulic pilot and manual operation, rated 40 L/min and up to 250 bar, designed for reliable mobile hydraulics across -40°C to +80°C and 15–75 cSt oils.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This 4-spool monoblock directional valve is built for mobile machinery requiring multiple actuator control in a compact, leak-resistant block design. Dual control (hydraulic pilot + manual) supports flexible installation: remote/pilot actuation for operator comfort and optional manual operation for direct control or backup. Performance highlights include 40 L/min rated flow, 250 bar max pressure, stable operation with 15–75 mm²/s hydraulic oil, and wide ambient tolerance from -40°C to +80°C for cold-start and outdoor duty. Typical applications include loaders, excavators, skid steers, telehandlers, forklifts, aerial platforms, dumpers, and tractor front-end loaders. OEM/ODM services available for wholesale, private label, and customization such as spool function, port/thread type, relief settings, and hydraulic circuit options to match your equipment and market requirements.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic and Manual, Cable, Joystick, Solenoid and Joystick |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Max Pressure | 250 bar (3600 psi) |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Structure Type | Monoblock valve |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
