40 cc/rev cam-plate type hydraulic gear pump designed for mobile and industrial hydraulic systems, delivering stable flow at up to 20 MPa rated pressure (25 MPa max) with multiple rotation, flange, and shaft options for OEM integration.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This 40 cc/rev gear pump is engineered for reliable fluid power on mobile equipment and industrial vehicles where consistent flow, compact installation, and durability are required. Rated pressure is 20 MPa (2900 psi) with a maximum pressure of 25 MPa (3625 psi). Rated speed is 2200 r/min and maximum speed is 3000 r/min for fast hydraulic response. Configuration options include right-hand (clockwise) or left-hand (counter-clockwise) rotation, A-oval flange or B-square flange mounting, and H rectangle spline shaft for secure torque transmission. Typical applications include steering/implement circuits and auxiliary hydraulics on forklifts, telehandlers, skid steers, mini/midi excavators, wheel loaders, backhoe loaders, aerial platforms, and tractors. Available for manufacturing supply, OEM/ODM, private label, customization, wholesale, and distributor/agent cooperation.
| CBHS-F4 Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 20 cc/rev, 16 cc/rev |
| Rated Pressure | 20 MPa (2900 psi) |
| Max Pressure | 25 MPa (3625 psi) |
| Rated Speed | 2200 r/min |
| Max Speed | 3000 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise) |
| Structure | Cam Plate Type |
| Flange Version | A-Oval Flange, B-Square Flange |
| Shaft Type | H: Rectangle Spline |
