Electro-hydraulic 5-section monoblock directional valve designed for mobile machinery multi-function control, delivering 80 L/min rated flow and up to 315 bar max pressure with reliable operation across wide viscosity and ambient temperature ranges.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
This 5-spool electro-hydraulic monoblock directional valve is built for compact, high-integration mobile hydraulic systems where multiple actuators must be controlled from electrical signals (e.g., cab switches/joystick controllers). The monoblock structure helps reduce external leakage points and improves installation simplicity compared with multi-piece stack designs.
Key performance:
- Rated flow: 80 L/min (21.2 US gpm) for high-flow functions on loaders, telehandlers, aerial platforms, and similar equipment.
- Max pressure: 315 bar (4600 psi) suitable for demanding work circuits.
- Fluid compatibility: operating viscosity 15–75 mm²/s for common hydraulic oils.
- Environment: -40°C to +80°C ambient range for cold climate and hot-duty applications.
Typical applications:
- Construction & earth moving: skid steer loaders, wheel loaders, backhoe loaders, mini-excavators, motor graders.
- Material handling & industrial vehicles: forklifts, telehandlers, aerial platforms.
- Agriculture: tractors and front-end loaders.
Supply capabilities:
- Manufacturer direct for global wholesale, OEM/ODM, private label, and custom configurations (ports, circuit functions, electrical interface, mounting options) to match your machine platform and distribution needs.
| P80 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Rated Flow | 80 L/min (21.2 US gpm) |
| Max Pressure | 315 bar (4600 psi) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
