63 cc/rev cast-iron gear pump designed for mobile hydraulic systems, offering bidirectional rotation, up to 25 MPa max pressure, and reliable operation up to 2500 r/min with ISO-4 or UNI-3 flange options and rectangle spline shaft.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
Key specs: 63 cc/rev displacement; rated pressure 20–22 MPa; max pressure 23–25 MPa; rated speed 2200 r/min; max speed 2500 r/min; bidirectional rotation. Construction: cast iron housing for durability and wear resistance in demanding duty cycles. Mounting & interface: ISO-4 mounting holes or UNI-3 mounting holes; H type rectangle spline shaft for stable torque transmission and easy driveline matching. Applications: suitable for mobile and industrial hydraulic power units in forklifts, telehandlers, stackers, aerial platforms, compact loaders, excavators, dumpers, tractors and similar equipment. Supply options: manufacturer direct support for OEM/ODM, private label, customization, bulk wholesale, and distributor/agent cooperation for global markets.
| CBHW Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 32 cc/rev, 50 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 25 cc/rev, 43 cc/rev, 90 cc/rev |
| Rated Pressure | 20 MPa (2900 psi), 22 MPa (3190 psi) |
| Max Pressure | 23 MPa (3335 psi), 25 MPa (3625 psi) |
| Rated Speed | 2200 r/min |
| Max Speed | 2500 r/min |
| Rotation | /: (Bidirectional) |
| Structure | External Gear Pump, Internal Gear Pump |
| Material | Cast Iron |
| Shaft Type | H: Rectangle Spline |
| Flange Version | ISO-4 Mounting Holes, UNI-3 Mounting Holes |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
