A 63 cc/rev cast-iron internal gear pump with B-square flange mounting, designed for stable flow delivery in mobile and industrial hydraulic systems. Rated 16 MPa with up to 20 MPa max pressure, and supports right or left rotation for flexible installation.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
Key specifications: 63 cc/rev displacement; rated pressure 16 MPa (2320 psi), max pressure 20 MPa (2900 psi); rated speed 2000 r/min, max speed 2200 r/min. Construction: internal gear structure for smooth output and low pulsation; robust cast-iron housing for durability in harsh duty cycles. Mounting/connection options: B-square flange version; shaft choices include rectangle spline (H) or plain key (P); rotation available in right (clockwise) or left (counter-clockwise) to match system layout. Typical applications: lift and drive hydraulics, auxiliary circuits, steering and implement functions on forklifts, telehandlers, skid steer loaders, compact excavators/loaders, aerial platforms, tractors and other mobile machinery. Supply capability: factory direct manufacturing with OEM/ODM, private label, customization, bulk wholesale, and distributor/agent sourcing for global markets.
| JHP Tandem Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 10 cc/rev, 40 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 16 cc/rev |
| Rated Speed | 2000 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise) |
| Rated Pressure | 16 MPa (2320 psi) |
| Shaft Type | H: Rectangle Spline, P: Plain Key |
| Max Pressure | 20 MPa (2900 psi) |
| Structure | Internal Gear Pump |
| Max Speed | 2200 r/min |
| Flange Version | B-Square Flange |
| Material | Cast Iron |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
