A 90 cc/rev cast-iron hydraulic pump designed for mobile and industrial hydraulic systems, offering 23 MPa rated pressure (25 MPa max), bidirectional rotation, ISO 4-bolt mounting, and an H-type rectangle spline shaft for reliable power delivery in demanding equipment.
global shipping world wide
Online Service For 24 X 7
Support OEM customization
• Performance: 90 cc/rev displacement; rated pressure 23 MPa (3335 psi), max 25 MPa (3625 psi); rated speed 2000 r/min, max 2500 r/min.
• Installation: ISO-4 mounting holes flange for easy interchange and standardized fitment.
• Drive interface: H-type rectangle spline shaft to handle high torque transmission and stable coupling.
• Durability: Cast iron construction for strength, wear resistance, and heat stability in continuous-duty applications.
• Operation: Bidirectional rotation supports flexible plumbing and multi-market configurations.
• Typical applications: Hydraulics for forklifts, telehandlers, aerial platforms, skid steer loaders, mini-excavators, wheel loaders, backhoe loaders, dumpers, tractors with front-end loaders, and sweepers.
• Supply capabilities: Manufacturer direct support for OEM manufacturing, contract production, private label, customization, bulk/wholesale supply, and distributor/agent partnership opportunities for global markets.
| CBHST1-ISO Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 50 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 34 cc/rev, 43 cc/rev, 120 cc/rev |
| Rated Pressure | 23 MPa (3335 psi) |
| Max Pressure | 25 MPa (3625 psi) |
| Rated Speed | 2000 r/min |
| Max Speed | 2500 r/min |
| Rotation | /: (Bidirectional) |
| Structure | Swashplate |
| Material | Cast Iron |
| Flange Version | ISO-4 Mounting Holes |
| Shaft Type | H: Rectangle Spline |
We provide OEM/ODM services. When your product orders reach a certain value, we can offer a variety of customization services, including labels, packaging, product colors, and more.
We support multiple currencies and diverse payment methods, such as T/T, L/C, Alibaba platform, China Manufacturing Payment Platform, bank transfer, and more.
We can provide samples, and the sample costs will be refunded to you in the form of deducted payments in the later stages.
